158 Upgrade and Maintenance Manual
TX1310 M1
Processor
11.3 Replacing the heat sink
11.3.1 Preliminary steps
Ê "Shutting down the server" on page 40
Ê "Disconnecting the server from the mains" on page 41
Ê "Removing the side cover" on page 42
11.3.2 Removing the heat sink
Ê Remove the heat sink as described in section "Removing the heat sink" on
page 143.
Ê Remove the residual thermal paste from the processor surface.
Ê Clean the processor surface using a lint-free cloth.
11.3.3 Installing the new heat sink
Ê Remove the protective cover from the heat sink.
Ê Install the heat sink as described in section "Installing the heat sink" on
page 156.
11.3.4 Concluding steps
Ê "Installing the side cover" on page 53
Ê "Connecting the server to the mains" on page 54
Ê "Switching on the server" on page 55
Field Replaceable Unit
(FRU)
Hardware: 15 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
