226 Upgrade and Maintenance Manual
TX1310 M1
Appendix
No. Print Description
1 PWR1 Power supply connector
2 FRONTPANEL Front panel connector
3 PWR2 Power supply connector
4 RESET Reset
5 FAN CPU Connector for CPU fan
6 HDD LED Connector for HDD LED
7 FAN1 SYS Connector for system fan 1
8 USB 1 Connector for USB 1
9 FAN2 SYS Connector for system fan 2
10 SATA 1-5 SATA 1-5 connector
11 SATA 6 SATA 6 connector
12 FRONT USB Connector for USB Front
13 UFM Connector for UFM
14 TPM Connector for TPM
