52 Upgrade and Maintenance Manual
TX1310 M1
Basic hardware procedures
Figure 13: Connecting cables to the backup drive
Ê Connect all cables to the backup drive.
1 Power adapter cable (connected to power cable connector P7)
2 USB cable
/
