Chapter 8: Image Viewer
Definium 5000 X-Ray System 5197809-1EN Rev. 4 (13 February 2008) 8-10
Operator Manual © 2008 General Electric Company. All rights reserved.
User
Annotation
Places a text box on the image that you may add notes into.
Hide and
Show
Temporarily removes image annotations from the image. When
annotations are hidden, the button name changes to [SHOW]. Press
[SHOW] to see the annotations.
Erase Deletes the selected image annotation.
NOTE: Deleted annotations cannot be recovered.
Erase All Deletes all image annotations.
NOTE: Deleted annotations cannot be recovered.
RL Places a Right or Left marker on the image for reference.
NOTE: RL markers are only available when the image is open in a live exam.
Only one marker may be placed on an image.
Edit Opens a dialog box to edit or change the selected User Annotation
(notes).
Tool Description
