GE MEDICAL SYSTEMS PROPRIETARY TO GE
D
IRECTION 2294854-100, REVISION 3 LOGIQ™ 9 PROPRIETARY MANUAL
Chapter 5 Components and Functions (Theory) 5-13
Table 5-4 SCB2 2365739 LED Indications
LED
Number
LED Color LED Function
DS1 Green FPGA Programming Done (Passed)
DS2 Red i960 Fail
DS5 Green Toggles during Image Port Frames
DS6 Red Toggles during Image Port Frames
DS7 Red Crash
DS8 Yellow FIFO Error
DS9 Yellow Command Pause
DS10 Yellow Unused
DS11 Yellow Pause
DS12 Green Unused
DS13 Green Happy Light (toggles during Scan Sequence)
DS14 Green Happy Light (toggles during Scan Sequence)
