GE MEDICAL SYSTEMS PROPRIETARY TO GE
D
IRECTION 2294854-100, REVISION 3 LOGIQ™ 9 PROPRIETARY MANUAL
3-2 Section 3-2 - Installation Reminders
Section 3-2
Installation Reminders
3-2-1 Average Installation Time
3-2-2 Installation Warnings
1.) Since the LOGIQ™ 9 weighs approximately 225 kg (500 lb.) without options, preferably two people
should unpack it. Two people are also preferable for installing any additional items in excess of 35
pounds.
2.) There are no operator serviceable components. To prevent shock, do not remove any covers or
panels. Should problems or malfunctions occur, unplug the power cord. Only qualified service
personnel should carry out servicing and troubleshooting.
3.) After being transported, the unit may be very cold or hot. If this is the case, allow the unit to
acclimate before you turn it on. It requires one hour for each 2.5°C increment it's temperature is
below 10°C or above 40°C.
3-2-2-1 Brake Pedal Operation
3-2-2-2 Operator I/O Panel Position
If weight is placed on the Operator I/O Panel in it’s extended position the console could tip over.
Table 3-2 Average Installation Time
Description Average Installation Time Comments
Unpacking the scanner 0.5 hours
Scanner wo/options 0.5 hours Dependant on the required configuration
DICOM Option 0.5 - 2.0 hours Dependant on the configuration amount
InSite Option 0.5 hours
CAUTION
Equipment damage possibility. Turning the system on without acclimation after arriving at site
may cause the system to be damaged.
Table 3-3 Acclimation Time
°C
60 55 50 45 40 35 30 25 20 15 10 5 0 -5 -10 -15 -20 -25 -30 -35 -40
°F
140 131 122 113 104 96 86 77 68 59 50 41 32 23 14 5 -4 -13 -22 -31 -40
hrs
864200000002468101214161820
WARNINGWARNING
REMEMBER: If the front caster swivel lock is engaged for transportation, pressing the
release pedal once disengages the swivel lock. You must depress the release pedal a
second time to engage the brake.
WARNINGWARNING
The system should NOT be moved with the Operator I/O Panel extended. Move the
Operator I/O Panel to it’s centered and locked position. Lower the Operator I/O Panel
as much as possible before moving the system.
