Chapter 5 Components and Functions (Theory) 5-43
5-7-6 Outputs
DC Voltage
AUDIO
Table 5-25 DC Output Voltages
Output Description Connection to
+5 VDC
+12 VDC
From BEP
Spare (Connector J21)
+5 VDC,
-15 VDC,
-5 VDC
analog
From Card Rack
+5 VDC
+12 VDC
From BEP
Not Used
+5 VDC,
-15 VDC,
-5 VDC
analog
From Card Rack
+5 VDC,
+15 VDC,
From Card Rack Not Used
+12 VDC From BEP
Top Console
+15 VDC From Card Rack
+5 VDC
+12 VDC
From BEP
EIO
+5 VDC,
+15 VDC,
-5 VDC
analog
+6 VDC
analog
From Card Rack
Table 5-26 Audio Outputs
Output Description Connection to
Audio (two
channels)
Audio (Doppler sound) from MBD (IMP), VCR, BEP
Top Console speakers and BEP
VCR and IEIO
