Chapter 7 Diagnostics/Troubleshooting 7-59
7-12-6 Minimum Cable Configuration for System to Boot
The following cables must be connected between the INT I/O board and the rest of the system:
• Cables to Hard Disk (inside Back End Processor)
• Patient I/O cable to Patient I/O box
• I/O RS-232 serial cable to Front Panel
• ACCTRL cable between INT I/O and ACCTRL (power-on signal)
• DC Power cable to Front Panel
• Cables to the monitor
All other cables can be removed and the system will still boot.
7-12-7 Minimum Cable Configuration for System to Scan
The following cables must be connected between the INT I/O board and the rest of the system:
• Cables to Hard Disk (inside Back End Processor)
• Patient I/O cable to Patient I/O box
• I/O RS-232 serial cable to Front Panel
• ACCTRL cable between INT I/O and ACCTRL (power-on signal)
• DC Power cable to Front Panel
• Cables to the monitor
• PCI Cable from BEP to SCB
