8-3-5 Back-End Processor Installation Procedure
1.) Slide the Back End Processor front first into the frame. Notice it does not fit flush with the side frame.
2.) Fasten the 6 screws to secure the back-end processor to the frame.
3.) Plug in the cables. See Table 8-4 or Tab l e 8- 5 for cable identification.
4.) Install the lower rear cover as shown in Section 8-2-6 on page 8-10 (click here to view the cover
installation video)
5.) Install the upper rear cover shown in Section 8-2-3 on page 8-7.
6.) Install both left- and right-side covers as shown in Section 8-2-2 on page 8-5.
7.) Refer to the Software Laoding procedures to install the proper Base Image Software and
Applications software to the new BEP.
8.) If required, Power On/Boot-up the system as described in Section 4-3-1 on page 4-2.
CAUTION
These mechanical parts may have sharp edges. Take care when holding these parts so you
do not scratch or cut your skin.
NOTICE
Be careful to not pinch any of the cables.
