GE MEDICAL SYSTEMS PROPRIETARY TO GE

IRECTION 2294854-100, REVISION 3 LOGIQ™ 9 PROPRIETARY MANUAL

3-12 Section 3-6 - System Configuration

3-6-4-1 External I/O Pin Outs

Table 3-6 S-Video Connector, 4 Pin

Pin No Output Signal Description

1 SVIDEO OUT/IN YG Y (Luma) GND

2 SVIDEO OUT/IN CG C (Chroma) GND

3 SVIDEO OUT/IN Y Y (Luma) SIGNAL

4 SVIDEO OUT/IN C C (Chroma) SIGNAL

Table 3-7 S-VGA Connector, Shrinked Sub-D 15 Pin

Pin No Output Signal Description

1 VGA OUT1 R Red

2 VGA OUT1 G Green

3 VGA OUT1 B Blue

4, 9,11,12,15 N/C N/C

5, 6, 7, 8, 10 GND GND

13 VGA OUT1 HS H Sync

14 VGA OUT1 VS V Sync

Table 3-8 USB (A) Connector

Pin No Output Signal Description

1 VCC USB Power Supply

2 - Data USB Data (-)

3 + Data USB Data (+)

4 GND USB Power Ground

Table 3-9 Ethernet Connector, RJ45 Modular 8 Pin

Pin No Output Signal Description

1 ETHER TD Ethernet RD+

2 ETHER TD Ethernet RD-

3 ETHER RD Ethernet TD+

6 ETHER RD Ethernet TD-

Others NC Non-connection
