GE MEDICAL SYSTEMS PROPRIETARY TO GE
D
IRECTION 2294854-100, REVISION 3 LOGIQ™ 9 PROPRIETARY MANUAL
Chapter 3 Installation 3-13
3-6-4-1External I/O Pin Outs (cont’d)
Table 3-10 Modem, RJ11 Modular 6 Pin
Pin No Output Signal Description
2 TEL L4 Telephone L4
3 TEL L2 Telephone L2
4 TEL L1 Telephone L1
5 TEL L3 Telephone L3
Others NC Non-connection
Table 3-11 Remote Expose 1 & 2 Connectors
Pin No Output Signal Description
1 SHUTTER/PRINT
2 Signal GND
Table 3-12 Footswitch Connector
Pin No Output Signal Description
1 Foot 1
2 Floating Ground
3 Foot 2
4 Floating Ground
5 Foot 3
