GE MEDICAL SYSTEMS PROPRIETARY TO GE
D
IRECTION 2294854-100, REVISION 3 LOGIQ™ 9 PROPRIETARY MANUAL
8-112 Section 8-27 - Lower Operator Panel Replacement Procedure
8-27-4 Operator Panel Removal Procedure
1.) Unscrew 13 screws under the Top Console and 4 behind LCD Display.
NOTE: 10 screws are 16 mm long and 7 are 25 mm.
2.) Unscrew 2 screws (6 mm) behind the Front Panel, located beside speakers on the shelf
undercover.
3.) Lift Operator Panel carefully in front first. Disconnect 3 connectors.
4.) Remove Operator Panel.
8-27-5 Operator Panel Installation Procedure
1.) Put the Operator Panel carefully on Top Console.
2.) Connect 3 connectors.
3.) Install the panel in correct position.
4.) Fasten 13 screws under the Top Console and 6 behind LCD Display.
