GE MEDICAL SYSTEMS PROPRIETARY TO GE
D
IRECTION 2294854-100, REVISION 3 LOGIQ™ 9 PROPRIETARY MANUAL
Chapter 8 Replacement Procedures 8-121
8-30-4 Trackball Removal Procedure
1.) Disconnect two (2) connectors at the trackball unit and 1 at the print between trackball unit and
operator panel. Remove trackball assembly.
2.) Unscrew four (4) Phillips screws on the print.
3.) Unscrew two (2) screws/nuts and remove trackball unit from print.
4.) Unscrew two (2) Phillips screws on the trackball housing.
5.) Open trackball housing, and remove trackball.
8-30-5 Trackball Installation Procedure
1.) Install trackball in housing. Replace cover and fasten removed screws.
2.) Install the trackball unit on the print and fasten removed screws/nuts.
3.) Install trackball assembly on the Operator Panel and fasten 4 screws.
4.) Connect three (3) connectors.
5.) Install Operator Panel as described in Section Section 8-27 on page 8-111.
