5-28 Section 5-4 - Back End Processor (BEP)
5-4-12-5 USB to Serial Adapter Cable Setup (RS232 Serial Port Connector on the External I/O)
The Prolific USB to RS232 Adapter Cable (black one) should be properly set up when the Base Image
Load is applied to the system. However, if you need to set a specific parameter for the USB COM Port
(COM1) perform the following steps:
- After booting up with the Service Dongle, entering Maintenance Mode and Windows, select
My Computer>Properties>Hardware Tab>Device manager.
- Under Ports (COM & LPT) select “Prolific USB-to-Serail Comm/Port (COM 3)” and select
Properties.
- Under the Port Settings TAB you can set the Bits per second, Data bits, Parity Stop Bits and
Flow Control to the desired values.
5-4-13 Outputs
Table 5-9 Factory Default Values
Signal Name Setting
Bits Per Second 9600
Data Bits 8
Parity None
Stop Bits 1
Flow Control None
Table 5-10 Output Signals
Signal Name Description Signal Path
+5VDC DC Voltage PC2IO > IIO
+12VDC DC Voltage PC2IO > IIO
PS_ON* TBD (Active Low) PC2IO > IIO > Card Rack
Standby TBD PC2IO > IIO > Top Console
SVideo SVideo Out PCVIC > PC2IO > IIO > EIO
CVideo Composite Color Video PCVIC > PC2IO > IIO > EIO
VGA VGA High Resolution Video to External Video Screen PCVIC > PC2IO > IIO > EIO
VGA
VGA High Resolution Video to Internal Video Screen (Top
Console)
BEP > Top Console
BW Video RGB
BW Video from RGB.
This signal is not used on LOGIQ™ 9
PCVIC > PC2IO > IIO > EIO
This signal is not used on LOGIQ™ 9
Audio Out Audio Out from BEP
BEP > IIO > Internal VCR
BEP > IIO > EIO > External VCR
TRIG Video Trig Signal PC2IO > IIO > EIO
