5-42 Section 5-7 - Internal I/O
5-7-5Inputs (cont’d)
Serial Ports
Control Signals
Table 5-23 Serial Ports
Input Description Connection from
USB Standard USB Serial Bus BEPM - Top console
USB Standard USB Serial Bus BEPM - IEIO
Ethernet Standard Ethernet BEPM - IEIO
RS232 Standard RS232 Serial Bus BEPM COM1 - IEIO
RS232 Standard RS232 Serial Bus BEPM COM2 - IEIO
RS232 Standard RS232 Serial Bus PC2IO - Spare (J16)
RS232 Standard RS232 Serial Bus PC2IO - VCR (J16)
RS232 PC2IO - Color printer (Connector J16)
RS232 PC2IO – UPS (Connector J16)
Table 5-24 Control Signals
Input Description Connection from
Control signals Spare MBD/FEC (Connector J16)
Control signals Spare MBD/FEC (Connector J16)
Trace trigger To EIO PC2IO (Connector J16)
Fan control signals To AC Power MBD (Connector J16)
Power control
signals
To MBD and AC Power PC2IO (Connector J16)
Power on/off To Relay
Top Console ON/OFF Switch and EIO
Test (Connector J16)
Standby To Top Console PC2IO (Connector J16)
