GE MEDICAL SYSTEMS PROPRIETARY TO GE
D
IRECTION 2294854-100, REVISION 3 LOGIQ™ 9 PROPRIETARY MANUAL
Chapter 8 Replacement Procedures 8-149
8-36-4 Rear Caster Removal Procedure (cont’d)
7.) The system is now nearly balanced between one Front and one Rear Caster (illustrated in this
Procedure; Left Front and Right Rear).
8.) Make the System rest on both Front Casters and lift the Rear Caster. Put the Wooden Wedge under
the AC Transformer. This will stabilize the System with the Rear Caster free from the floor.
Figure 8-155 Activate Rear Brakes
Figure 8-156 System stabilized with rear Caster free from the floor
Rear Wheel free
from the floor
Wooden Wedge under
AC Transformer
To Next Page
