9-20 Section 9-13 - Back End Processor Assembly
NOTE: * Contact the OnLine Center. Provide the BEP Part Number, Serial Number and PSP Rev Level
Table 9-14 Back End Processor Assembly
Item Part Name Part Number Description Qty FRU
471
Back End Processor (BEP1)
2266548-3 BEP1 - P3 Processor 1 1
472
Back End Processor (BEP1)
w/ 3-D Option
2266548-4
P3 Processor with 3-D “Flock of Birds” option
(PCI Bird Transmitter & Receiver NOT Included)
11
481
Back End Processor (BEP2.0)
2348186-3 P4 Processor 1 1
482
Back End Processor (BEP 2.0)
w/ 3-D Option
2348186-4
P4 Processor with 3-D “Flock of Birds” option installed
(PCI Bird Transmitter & Receiver NOT Included)
1 1
484
Back End Processor (BEP2.1)
2348186-13 P4 Processor with Digital VIC Card 1 1
485
Back End Processor (BEP 2.1)
w/ 3-D Option
2348186-14
P4 Processor (Digital VIC Card)
with 3-D “Flock of Birds” option installed
(PCI Bird Transmitter & Receiver NOT Included)
1 1
491
Back End Processor (BEP2.2)
2348186-63 With Version 2.3 Power Supply 1 1
492
Back End Processor (BEP 2.2)
w/ 3-D Option
2348186-64 With Version 2.3 Power Supply 1 1
483
Back End Processor Power Supply
2348186-38 Version 2.3 For ALL BEPs 1 1
473
3-D Externals - PCI Bird Transmitter
2301019-4 Option Kit 1 1
474
3-D Externals - PCI Bird Receiver
2301019-5 Option Kit 1 1
475
Global Modem Assembly
2245794
Multi-Tech - New installation requires cable kit
#2358850 -Same as Vivid 7 -
1 1
476
BEP Battery Assembly
2266548-5
Computer UPS Battery, located inside BEP Assy.
Expected battery life is 3 years
-Same as Vivid 7 -
12
477
Base Image Load Software
2307061-xx * Operating System Software - Specific to the BEP1.x.x 1 2
477A
Base Image Load Software
2352186-xx* Operating System Software - Specific to the BEP2.x.x 1 2
477B
Base Image Load Software
2371612-2 Operating System Software - Specific to the BEP3.x.x 1 2
478
Applications Software
2307060-xx *
Ultrasound Operation Software, includes service
platform and diagnostics
1 2
490
Hard Disk Drive (HDD) BEP 1
2366650 Will need to transfer mounting tray to new HDD 1 1
490A
Hard Disk Drive (HDD) BEP 2.x
2348186-31 Comes with bracket or mounting tray 1 1
486
CD-RW Drive
2348186-37 BEP 2.x Only -Same as Vivid 7 - 11
487
Patient I/O Module
2348186-22 BEP 2.x Only -Same as Vivid 7 - 11
488
MOD Drive
2348186-23 BEP 2.0 Only - 1.3 Gigabyte IDE - 3.5 inch 1 1
489
Fan
2348186-24
Mounted on BEP Chassis Cover
-Same as Vivid 7 -
1 1
