GE P24DM User Manual

Object
Request
(Library will parse)
Response
(Library will respond with)
Object
Number
Variation
Number
Description
Function Codes (dec) Qualifier Codes
(hex)
Function Codes
(dec)
Qualifier Codes (hex)
34 0 Analog Input Deadband (Variation
0 is used to request default
variation)
1 (read) 00, 01
06
07, 08
17, 27, 28
(start-stop)
(no range, or all)
(limited qty)
(index)
34 1 16 Bit Analog Input Deadband 1 (read) 00, 01
06
07, 08
17, 27, 28
(start-stop)
(no range, or all)
(limited qty)
(index)
129 response 00, 01
17, 28
(start-stop)
(index - see note 2)
2 (write) 00, 01
07, 08
17, 27, 28
(start-stop)
(limited qty)
(index)
34 2
(default - see
note 1)
32 Bit Analog Input Deadband 1 (read) 00, 01
06
07, 08
17, 27, 28
(start-stop)
(no range, or all)
(limited qty)
(index)
129 response 00, 01
17, 28
(start-stop)
(index - see note 2)
2 (write) 00, 01
07, 08
17, 27, 28
(start-stop)
(limited qty)
(index)
34 3 Short Floating Point Analog Input
Deadband
1 (read) 00, 01
06
07, 08
17, 27, 28
(start-stop)
(no range, or all)
(limited qty)
(index)
129 response 00, 01
17, 28
(start-stop)
(index - see note 2)
2 (write) 00, 01
07, 08
17, 27, 28
(start-stop)
(limited qty)
(index)
40 0 Analog Output Status (Variation 0
is used to request default
variation)
1 (read) 00, 01
06
07, 08
17, 27, 28
(start-stop)
(no range, or all)
(limited qty)
(index)
40 1
(default - see
note 1)
32-Bit Analog Output Status 1 (read) 00, 01
06
07, 08
17, 27, 28
(start-stop)
(no range, or all)
(limited qty)
(index)
129 response 00, 01
17, 28
(start-stop)
(index - see note 2)
40 2 16-Bit Analog Output Status 1 (read) 00, 01
06
07, 08
17, 27, 28
(start-stop)
(no range, or all)
(limited qty)
(index)
129 response 00, 01
17, 28
(start-stop)
(index - see note 2)
40 3 Short Floating Point Analog
Output Status
1 (read) 00, 01
06
07, 08
17, 27, 28
(start-stop)
(no range, or all)
(limited qty)
(index)
129 response 00, 01
17, 28
(start-stop)
(index - see note 2)
41 1 32-Bit Analog Output Block 3
4
5
6
(select)
(operate)
(direct op)
(dir. op, noack)
17, 28
27
(index)
(index)
129 response echo of request
41 2 16-Bit Analog Output Block 3
4
5
6
(select)
(operate)
(direct op)
(dir. op, noack)
17, 28
27
(index)
(index)
129 response echo of request
41 3 Short Floating Point Analog
Output Block
3
4
5
6
(select)
(operate)
(direct op)
(dir. op, noack)
17, 27, 28 (index) 129 response echo of request
50
1
(default - see
note 1)
Time and Date
1 (read) 07 (limited qty = 1) 129 response 07 (limited qty = 1)
2 (write) 07 (limited qty = 1)
60 0 Not defined
60 1 Class 0 Data 1 (read) 06 (no range, or all)
60 2 Class 1 Data 1 (read) 06
07, 08
(no range, or all)
(limited qty)
22 (assign class) 06 (no range, or all)
60 3 Class 2 Data 1 (read) 06
07, 08
(no range, or all)
(limited qty)
22 (assign class) 06 (no range, or all)
60 4 Class 3 Data 1 (read) 06
07, 08
(no range, or all)
(limited qty)
P543i/P545i Chapter 22 - Communications
P54x1i-TM-EN-1 583
