6 POWER PROTECTION FUNCTIONS

6.1 REVERSE POWER PROTECTION

Pick-up Setting +/- 10%

Reverse power drop-off 0.95 x Setting +/- 10%

Angle variation pick-up +/- 2°

Angle variation drop-off +/- 2.5°

Operating time +/- 2% or 50 ms, whichever is greater

Repeatability < 5%

Disengagement time <50 ms

tRESET +/- 5%

Instantaneous operating time < 50 ms

Chapter 21 - Technical Specifications P24xM

444 P24xM-TM-EN-2.1
