Ethernet, which is becoming more and more widely used in substations, in favour of RS485. Using Ethernet in the
substation offer
s many advantages, most significantly including:
Ethernet allows high-speed data rates (currently 100 Mbps, rather than tens of kbps or less used by most
serial protocols)
Ethernet provides the possibility to have multiple clients
Ethernet is an open standard in every-day use
There is a wide range of Ethernet-compatible products that may be used to supplement the LAN installation
(hubs, bridges, switches)
6.5.2 IEC 61850 INTEROPERABILITY
A major benefit of IEC 61850 is interoperability. IEC 61850 standardizes the data model of substation IEDs, which
allows inter
operability between products from multiple vendors.
An IEC 61850-compliant device may be interoperable, but this does not mean it is interchangeable. You cannot
simply replace a product from one vendor with that of another without reconfiguration. However the terminology
is pre-defined and anyone with prior knowledge of IEC 61850 should be able to integrate a new device very quickly
without having to map all of the new data. IEC 61850 brings improved substation communications and
interoperability to the end user, at a lower cost.
6.5.3 THE IEC 61850 DATA MODEL
The data model of any IEC 61850 IED can be viewed as a hierarchy of information, whose nomenclature and
categorization is defined and standar
dized in the IEC 61850 specification.
V01008
Physical Device (network address)
Logical Device : IEDs 1 to n
LN1: XCBR LN2: MMXU
Logical Nodes : 1 to n
Data Objects
Data Attributes
stVal q t PhA PhCPhB
Pos A
Figure 158: Data model layers in IEC 61850
The lev
els of this hierarchy can be described as follows:
Data Frame format
Layer Description
Physical Device
Identifies the actual IED within a system. Typically the device’s name or IP address can be used (for
example Feeder_1 or 10.0.0.2.
Logical Device
Identifies groups of related Logical Nodes within the Physical Device. For the MiCOM IEDs, 5 Logical
Devices exist: Contr
ol, Measurements, Protection, Records, System.
Chapter 16 - Communications P24xM
352 P24xM-TM-EN-2.1
