5.3 40TE FRONT PANEL
Figure 12: Front panel (40TE)
The figur
e shows the front panel for the 40TE variant.
It consists of:
● LCD display
● Keypad
● USB port
● 4 x fixed function tri-colour LEDs
● 8 x programmable tri-colour LEDs
● 3 x function keys
● 3 x tri-colour LEDs for the function keys
5.4 KEYPAD
The keypad consists of the following keys:
4 arrow keys to navigate the menus (organised around the Enter key)
An enter key for executing the chosen option
P24xM Chapter 3 - Hardware Design
P24xM-TM-EN-2.1 39
