8.3 DISTURBANCE RECORDS
Disturbance Records Measurement Accuracy
Minimum record duration 0.1 s
Maximum record duration 10.5 s
Minimum number of records at 10.5 seconds 15
Magnitude and relative phases accuracy ±5% of applied quantities
Duration accuracy ±2%
Trigger position accuracy ±2% (minimum Trigger 100 ms)
8.4 EVENT, FAULT AND MAINTENANCE RECORDS
Event, Fault & Maintenance Records
Record location Flash memory
Viewing method Front panel display or MiCOM S1 Agile
Extraction method Extracted via the USB port
Number of Event records Up to 2048 time tagged event records
Number of Fault Records Up to 10
Number of Maintenance Records Up to 10
Chapter 21 - Technical Specifications P24xM
448 P24xM-TM-EN-2.1
