GE P24DM - Communication Functions

To Next Page

To Previous Page

Measurement Function Details

Time Stamping of Opto-inputs Yes

4.4 COMMUNICATION FUNCTIONS

The device offers the following communication functions:

Communication Function Details

Local HMI Yes

Multi-language HMI (English, French, German, Italian,

Portuguese, Spanish, Russian)

Yes

Front port USB

1st rear port RS485 or IRIG-B

2nd rear port (optional) RS485 or IRIG-B or single channel Ethernet or dual redundant Ethernet

Serial Protocols available IEC 60870-5-103, MODBUS, Courier, DNP3

Ethernet Protocols available IEC 61850, DNP3 over Ethernet, PRP, HSR

Virtual inputs 64

Cyber-security Yes

Enhanced Studio (S1 Agile) Yes

P24xM Chapter 1 - Introduction

P24xM-TM-EN-2.1 9
