10 INTER-PSL INPUTS AND OUTPUTS
To make the design of PSL schemes easier, P40 Agile provides a range of DDB signals for conncting PSL Inputs to
PSL Outputs. these ar
e called Inter-PSL inputs and outputs. This facility allows you to map many PSL input signals
to a single Inter-PSL output signal, many PSL output signals to a single Inter-PSL input signal, and to join the Inter-
PSL input signal to an Inter-PSL output signal. The Inter-PSL input signals can also be used to directly trigger the
Disturbance Recorder.
