9 CONTROL INPUTS
The control inputs are software switches, which can be set or reset locally or remotely. These inputs can be used to
trigger any PSL f
unction to which they are connected. There are three setting columns associated with the control
inputs: CONTROL INPUTS, CTRL I/P CONFIG and CTRL I/P LABELS. These are listed in the Settings and Records
appendix at the end of this manual.
P24xM Chapter 15 - Digital I/O and PSL Configuration
P24xM-TM-EN-2.1 301
