Operating time
Operating time (Freq. Av Cycles setting = 0) <125 ms
Reference conditions: To maintain accuracy, the minimum time delay setting should be:
Dt> 0.375 x Df + 0.23 (f0r Df setting <1
Hz)
Dt> 0.156 x Df + 0.47 (for Df setting >= 1 Hz)
5.6 LOAD RESTORATION
Pick-up Setting +/- 2.5%
Drop-off 0.95% x Setting +/- 2.5%
Restoration timer +/- 2% or 50 ms, whichever is greater
Holding timer +/- 2% or 50 ms, whichever is greater
5.7 ANTI-BACKSPIN
Pick-up Setting ±5%
DT operation ±2% or 50 ms whichever is greater
Repeatability <1%
P24xM Chapter 21 - Technical Specifications
P24xM-TM-EN-2.1 443
