2 COMMUNICATION INTERFACES
The MiCOM P40 Agile products have a number of standard and optional communication interfaces. The standard
and optional har
dware and protocols are summarised below:
Port Availability Physical Layer Use Data Protocols
Front Standard USB
Local settings
Firmw
are download
Courier
Rear serial port 1 Standard RS485 / K-Bus
SCADA
Remote settings
IRIG-B
Courier, MODBUS, IEC 60870-5-103, DNP3.0
Rear serial port 2
(order option)
Optional RS485
SCADA
Remote settings
IRIG-B
Courier
Rear Ethernet
port
Optional Ethernet/copper
SCADA
Remote settings
Courier, DNP3.0 over Ethernet, IEC 61850
(order option)
Rear Ethernet
port
Optional Ethernet/fibre
SCADA
Remote settings
Courier or DNP3.0 over Ethernet
(order option)
Note:
Optional communication boar
ds are always fitted into slot C and only slot C.
It is only possible to fit one optional communications board, therefore Serial and Ethernet communications are mutually
exclusive.
