Test Check Action
4
The IED resets when the power-up is complete. A record
err
or code is displayed.
Programmable scheme logic error due to excessive execution time. If
the IED powers up successfully, check the programmable logic for
feedback paths.
Other error codes relate to software errors on the main processor
board, contact the local service centre.
3.4 OUT OF SERVICE LED ON AT POWER-UP
Test Check Action
1
Using the IED menu, confirm the Commission Test or Test
Mode setting is Enabled. If it is not Enabled, go to test 2.
If the setting is Enabled, disable the test mode and make sure the Out of
Service LED is OFF.
2
Select the VIE
W RECORDS column then view the last
maintenance record from the menu.
Check for the H/W Verify Fail maintenance record. This indicates a
discr
epancy between the IED model number and the hardware. Examine
the Maint Data; cell. This indicates the causes of the failure using bit
fields:
Bit Meaning
0
The application 'type' field in the Cortec does not match the
softw
are ID
1
The 'subset' field in the model number does not match the
software ID
2
The 'platform' field in the model number does not match the
software ID
3
The 'product type' field in the model number does not
match the software ID
4
The 'protocol' field in the Cortec does not match the
software ID
5
The 'model' field in the Cortec does not match the software
ID
6
The first 'software version' field in the does not match the
software ID
7
The second 'software version' field in the Cortec does not
match the software ID
8 No VTs are fitted
9 No CTs are fitted
10 No Earth CT is fitted
11 No SEF CT is fitted
3.5 ERROR CODE DURING OPERATION
The IED performs continuous self-checking. If the IED detects an error it displays an error message, logs a
maintenance r
ecord and after a short delay resets itself. A permanent problem (for example due to a hardware
fault) is usually detected in the power-up sequence. In this case the IED displays an error code and halts. If the
problem was transient, the IED reboots correctly and continues operation. By examining the maintenance record
logged, the nature of the detected fault can be determined.
