1 CHAPTER OVERVIEW

The P24DM, P24NM provides a wide range of current protection functions. This chapter describes the operation of

these f

unctions including the principles, logic diagrams and applications.

This chapter contains the following sections:

Chapter Overview 73

Thermal Overload Protection 74

Overcurrent Protection Principles 84

Phase Overcurrent Protection 94

Current Setting Threshold Selection 101

Negative Sequence Overcurrent Protection 102

Earth Fault Protection 109

Sensitive Earth Fault Protection 130

Cold Load Pickup 138

Selective Logic 141

Timer Setting Selection 142

Blocked Overcurrent Protection 143

Second Harmonic Blocking 146

Stall protection 148

Number of Starts 158

Anti-Backspin Protection 162

P24xM Chapter 6 - Current Protection Functions
