Figure 161: Rack mounting of products
Products can be mechanically grouped into single tier (4U) or multi-tier arrangements using the rack frame. This
enables schemes using products from different product ranges to be pre-wired together before mounting.
Use blanking plates to fill any empty spaces. The spaces may be used for installing future products or because the
total size is less than 80TE on any tier. Blanking plates can also be used to mount ancillary components. The part
numbers are as follows:
Case size summation Blanking plate part number
5TE GJ2028 101
10TE GJ2028 102
15TE GJ2028 103
20TE GJ2028 104
25TE GJ2028 105
30TE GJ2028 106
35TE GJ2028 107
40TE GJ2028 108
3.2 SOFTWARE ONLY
It is possible to upgrade an existing device by purchasing software only (providing the device is already fitted with
the r
equisite hardware).
There are two options for software-only products:
● Your device is sent back to the General Electric factory for upgrade.
● The software is sent to you for upgrade. Please contact your local representative if you wish to procure the
services of a commissioning engineer to help you with your device upgrade.
Note:
Software-only products are licensed for use with devices with specific serial numbers.
Chapter 18 - Installation P24xM
386 P24xM-TM-EN-2.1
