10 MECHANICAL SPECIFICATIONS
10.1 PHYSICAL PARAMETERS
Physical Measurements
Case Types
20TE
30TE
40TE
Weight (20TE case) 2 kg – 3 kg (depending on chosen options)
Weight (30TE case) 3 kg – 4 kg (depending on chosen options)
Weight (40TE case) 5.5 kg
Dimensions in mm (w x h x l) (20TE case) W: 102.4mm H: 177.0mm D: 243.1mm
Dimensions in mm (w x h x l) (30TE case) W: 154.2mm H: 177.0mm D: 243.1mm
Dimensions in mm (w x h x l) (40TE case) W: 206.0mm H: 177.0mm D: 243.1mm
Mounting Panel or rack
10.2 ENCLOSURE PROTECTION
Against dust and dripping water (front face) IP52 as per IEC 60529:2002
Protection against dust (whole case) IP50 as per IEC 60529:2002
Protection for sides of the case (safety) IP30 as per IEC 60529:2002
Protection for rear of the case (safety) IP10 as per IEC 60529:2002
10.3 MECHANICAL ROBUSTNESS
Vibration test per EN 60255-21-1:1996 Response: class 2, Endurance: class 2
Shock and bump immunity per EN 60255-21-2:1995
Shock response: class 2, Shock withstand: class 1, Bump withstand:
class 1
Seismic test per EN 60255-21-3: 1995 Class 2
10.4 TRANSIT PACKAGING PERFORMANCE
Primary packaging carton protection ISTA 1C
Vibration tests 3 orientations, 7 Hz, amplitude 5.3 mm, acceleration 1.05g
Drop tests
10 drops from 610 mm height on multiple carton faces, edges and
corner
s
P24xM Chapter 21 - Technical Specifications
P24xM-TM-EN-2.1 451
