GE P24DM - Terminal Connections; IO Options

4 TERMINAL CONNECTIONS
4.1 I/O OPTIONS
Component I/O option A I/O option B I/O option C I/O option D I/O option E I/O option F I/O option G I/O option H I/O option J
Digital
inputs
8
(1 gr
oup of 3
and
1 group of 5)
11
(2 groups of
3 and
1 group of 5)
11
(1 group of 3,
1 group of 5
and
3 individual)
13
(1 group of 3
and
2 groups of
5)
3
(1 group of 3)
6
(1 group of 3
and
3 individual)
7
1 group of 5
and
2 individual)
10
1 group of 3,
1 group of 5
and 2
individual)
12
(2 groups of
5 and
2 individual)
Output
relays
8
(NO)
12
(NO)
12
(11 NO, 1 NC)
12
(NO)
4
(NO)
8
(7 NO, 1 NC)
8
(NO)
12
(NO)
12
(NO)
Note:
I/O options C, F, G, H and J are suitable for Trip Circuit Supervision (TCS) applications.
Note:
For details of t
erminal connections, refer to the Wiring Diagrams Appendix.
