Make, carry and break ac inductive 10 A for 1.5 s, 10000 operations (subject to the above limits)

Loaded contact 10000 operations min.

Unloaded contact 100000 operations min.

Operate time < 5 ms

Reset time < 10 ms

13.3 WATCHDOG CONTACTS

Use Non-programmable contacts for relay healthy/relay fail indication

Breaking capacity, dc resistive 30 W

Breaking capacity, dc inductive 15 W (L/R = 40 ms)

Breaking capacity, ac inductive 375 VA inductive (cos phi = 0.7)

13.4 SHORTING LINK

Maximum operating voltage 300Vrms, 300Vdc

Maximum operating current 20A

P24xM Chapter 21 - Technical Specifications

P24xM-TM-EN-2.1 455
