12 POWER SUPPLY
12.1 AUXILIARY POWER SUPPLY VOLTAGE
Nominal operating range
24-250 V DC +/-20%
110-240 V A
C -20% + 10%
Maximum operating range 19 to 300 V DC
Frequency range for AC supply 45 – 65 Hz
Ripple <15% for a DC supply (compliant with IEC 60255-11:2008)
12.2 NOMINAL BURDEN
Quiescent burden 20TE 5 W max.
30TE 6 W max.
30TE with 2nd rear
communications
6.2 W max.
30TE with Ethernet or TCS 7 W max.
40TE 8 W max.
Additions for energised relay outputs 0.26 W per output relay
Opto-input burden 24 V 0.065 W max.
48 V 0.125 W max.
110 V 0.36 W max.
220 V 0.9 W max.
12.3 AUXILIARY POWER SUPPLY INTERRUPTION
Standard
IEC 60255-11:2008 (dc)
IEC 61000-4-11:2004 (ac)
Quiescent / half load Full load
19.2 V – 110 V dc >110 V dc 19.2 V – 110 V dc >110 V dc
20TE 50 ms 100 ms 50 ms 100 ms
30TE 50 ms 100 ms 30 ms 50 ms
30TE with 2nd rear communications 30 ms 100 ms 20 ms 50 ms
30TE with Ethernet or TCS 50 ms 100 ms 20 ms 100 ms
30TE with Redundant Ethernet Board 50 ms 100 ms 10 ms 100 ms
40TE with 2nd rear communications 20 ms 100 ms 10 ms* 50 ms
* for voltages > 48 V dc
Not
e:
Maximum loading = all inputs/outputs energised. Quiescent or 1/2 loading = 1/2 of all inputs/outputs energised.
