Case width (TE) Case width (mm) Equivalent K series
20TE 102.4 mm (4 inches) KCGG140/142
30TE 154.2 mm (6 inches) KCEG140/142
40TE 203.2 mm (8 inches) KCEG140/142
3.2 20TE REAR PANEL
The 20TE rear panel consists of two MIDOS heavy duty terminal blocks.
Figure 5: 20TE rear panel
3.3 30TE REAR PANEL
The 30TE rear panel consists of either:
● Thr
ee MIDOS heavy duty terminal blocks
● Two MIDOS heavy duty terminal blocks and a communication board
● Two MIDOS heavy duty terminal blocks and a blanking panel
P24xM Chapter 3 - Hardware Design
P24xM-TM-EN-2.1 33
