Object
Request
(Librar
y will parse)
Response
(Library will respond with)
Object
Number
Variation
Number
Description
Function Codes (dec) Qualifier Codes
(hex)
Function Codes
(dec)
Qualifier Codes (hex)
40 1
(default - see
note 1)
32-Bit Analog Output Status 1 (read) 00, 01
06
07, 08
17, 27, 28
(start-stop)
(no range, or all)
(limited qty)
(index)
129 response 00, 01
17, 28
(start-stop)
(index - see note 2)
40 2 16-Bit Analog Output Status 1 (read) 00, 01
06
07, 08
17, 27, 28
(start-stop)
(no range, or all)
(limited qty)
(index)
129 response 00, 01
17, 28
(start-stop)
(index - see note 2)
40 3 Short Floating Point Analog
Output S
tatus
1 (read) 00, 01
06
07, 08
17, 27, 28
(start-stop)
(no range, or all)
(limited qty)
(index)
129 response 00, 01
17, 28
(start-stop)
(index - see note 2)
41 1 32-Bit Analog Output Block 3
4
5
6
(select)
(operate)
(direct op)
(dir. op, noack)
17, 28
27
(index)
(index)
129 response echo of request
41 2 16-Bit Analog Output Block 3
4
5
6
(select)
(operate)
(direct op)
(dir. op, noack)
17, 28
27
(index)
(index)
129 response echo of request
41 3 Short Floating Point Analog
Output Block
3
4
5
6
(select)
(operate)
(direct op)
(dir. op, noack)
17, 27, 28 (index) 129 response echo of request
50
1
(default - see
note 1)
Time and Date
1 (read) 07 (limited qty = 1) 129 response 07 (limited qty = 1)
2 (write) 07 (limited qty = 1)
60 0 Not defined
60 1 Class 0 Data 1 (read) 06 (no range, or all)
60 2 Class 1 Data 1 (read) 06
07, 08
(no range, or all)
(limited qty)
22 (assign class) 06 (no range, or all)
60 3 Class 2 Data 1 (read) 06
07, 08
(no range, or all)
(limited qty)
22 (assign class) 06 (no range, or all)
60 4 Class 3 Data 1 (read) 06
07, 08
(no range, or all)
(limited qty)
22 (assign class) 06 (no range, or all)
70 0 File Event - Any Variation 1 (read) 06
07, 08
(no range, or all)
(limited qty)
22 (assign class) 06 (no range, or all)
70 2 File Authentication 29 (authenticate) 5b (free-format) 129 response 5B (free-format)
70 3 File Command 25
27
(open)
(delete)
5b (free-format)
70 4 File Command Status 26
30
(close)
(abor
t)
5b (free-format) 129 response 5B (free-format)
70 5 File Transfer 1 (read) 5b (free-format) 129 response 5B (free-format)
70 6 File Transfer Status 129 response 5B (free-format)
70 7 File Descriptor 28 (get file info) 5b (free-format) 129 response 5B (free-format)
80 1 Internal Indications 1 (read) 00, 01 (start-stop) 129 response 00, 01 (start-stop)
No Object (function code only) 13 (cold restart)
No Object (function code only) 14 (warm restart)
No Object (function code only) 23 (delay meas.)
