GE P24DM - Page 356

Object
Request
(Librar
y will parse)
Response
(Library will respond with)
Object
Number
Variation
Number
Description
Function Codes (dec) Qualifier Codes
(hex)
Function Codes
(dec)
Qualifier Codes (hex)
30 1 32-Bit Analog Input 1 (read) 00, 01
06
07, 08
17, 27, 28
(start-stop)
(no range, or all)
(limited qty)
(index)
129 response 00, 01
17, 28
(start-stop)
(index - see note 2)
30 2 16-Bit Analog Input 1 (read) 00, 01
06
07, 08
17, 27, 28
(start-stop)
(no range, or all)
(limited qty)
(index)
129 response 00, 01
17, 28
(start-stop)
(index - see note 2)
30 3
(default - see
note 1)
32-Bit Analog Input without Flag 1 (read) 00, 01
06
07, 08
17, 27, 28
(start-stop)
(no range, or all)
(limited qty)
(index)
129 response 00, 01
17, 28
(start-stop)
(index - see note 2)
30 4 16-Bit Analog Input without Flag 1 (read) 00, 01
06
07, 08
17, 27, 28
(start-stop)
(no range, or all)
(limited qty)
(index)
129 response 00, 01
17, 28
(start-stop)
(index - see note 2)
30 5 Short floating point 1 (read) 00, 01
06
07, 08
17, 27, 28
(start-stop)
(no range, or all)
(limited qty)
(index)
129 response 00, 01
17, 28
(start-stop)
(index - see note 2)
32 0 Analog Change Event - Any
V
ariation
1 (read) 06
07, 08
(no range, or all)
(limited qty)
32 1
(default - see
note 1)
32-Bit Analog Change Event
without Time
1 (read) 06
07, 08
(no range, or all)
(limited qty)
129 response 17, 28 (index)
32 2 16-Bit Analog Change Event
without Time
1 (read) 06
07, 08
(no range, or all)
(limited qty)
129 response 17, 28 (index)
32 3 32-Bit Analog Change Event with
Time
1 (read) 06
07, 08
(no range, or all)
(limited qty)
129 response 17, 28 (index)
32 4 16-Bit Analog Change Event with
Time
1 (read) 06
07, 08
(no range, or all)
(limited qty)
129 response 17, 28 (index)
32 5 Short floating point Analog
Change Event without Time
1 (read) 06
07, 08
(no range, or all)
(limited qty)
129 response 17, 28 (index)
32 7 Short floating point Analog
Change Event with Time
1 (read) 06
07, 08
(no range, or all)
(limited qty)
129 response 17, 28 (index)
34 0 Analog Input Deadband (Variation
0 is used to request default
variation)
1 (read) 00, 01
06
07, 08
17, 27, 28
(start-stop)
(no range, or all)
(limited qty)
(index)
34 1 16 Bit Analog Input Deadband 1 (read) 00, 01
06
07, 08
17, 27, 28
(start-stop)
(no range, or all)
(limited qty)
(index)
129 response 00, 01
17, 28
(start-stop)
(index - see note 2)
2 (write) 00, 01
07, 08
17, 27, 28
(start-stop)
(limited qty)
(index)
34 2
(default - see
note 1)
32 Bit Analog Input Deadband 1 (read) 00, 01
06
07, 08
17, 27, 28
(start-stop)
(no range, or all)
(limited qty)
(index)
129 response 00, 01
17, 28
(start-stop)
(index - see note 2)
2 (write) 00, 01
07, 08
17, 27, 28
(start-stop)
(limited qty)
(index)
34 3 Short Floating Point Analog Input
Deadband
1 (read) 00, 01
06
07, 08
17, 27, 28
(start-stop)
(no range, or all)
(limited qty)
(index)
129 response 00, 01
17, 28
(start-stop)
(index - see note 2)
2 (write) 00, 01
07, 08
17, 27, 28
(start-stop)
(limited qty)
(index)
40 0 Analog Output Status (Variation 0
is used to request default
variation)
1 (read) 00, 01
06
07, 08
17, 27, 28
(start-stop)
(no range, or all)
(limited qty)
(index)
