GE P24DM - Page 495

P24xM Appendix C – Wiring Diagrams
P24xM-TM-EN-2.1 C2
MODEL
CORTEC
OPTION*
EXTERNAL CONNECTION DIAGRAM TITLE
DRAWING-
SHEET
ISSUE
BP24DM
IO option A MOTOR PROTECTION WITH VOLTAGE & PHASE CURRENT INPUTS AND E/F (8 I/P & 8 O/P) 10P24D01-1 B
IO option A MOTOR PROTECTION WITH VOLTAGE & PHASE CURRENT INPUTS AND SEF (8 I/P & 8 O/P) 10P24D02-1 B
IO option A
MOTOR PROTECTION WITH VOLTAGE & PHASE CURRENT INPUTS AND E/F (8 I/P & 8 O/P) WITH ETHERNET
MOTOR PROTECTION WITH VOLTAGE & PHASE CURRENT INPUTS AND E/F (8 I/P & 8 O/P) WITH DUAL COPPER ETHERNET
MOTOR PROTECTION WITH VOLTAGE & PHASE CURRENT INPUTS AND E/F (8 I/P & 8 O/P) WITH DUAL FIBRE ETHERNET
10P24D03-1
10P24D03-2
10P24D03-3
B
B
B
IO option A
MOTOR PROTECTION WITH VOLTAGE & PHASE CURRENT INPUTS AND SEF (8 I/P & 8 O/P) WITH ETHERNET
MOTOR PROTECTION WITH VOLTAGE & PHASE CURRENT INPUTS AND SEF (8 I/P & 8 O/P) WITH DUAL COPPER ETHERNET
MOTOR PROTECTION WITH VOLTAGE & PHASE CURRENT INPUTS AND SEF (8 I/P & 8 O/P) WITH DUAL FIBRE ETHERNET
10P24D04-1
10P24D04-2
10P24D04-3
B
B
B
IO option B
MOTOR PROTECTION WITH VOLTAGE & PHASE CURRENT INPUTS AND E/F (11 I/P & 12 O/P) WITH 2 RS485
MOTOR PROTECTION WITH VOLTAGE & PHASE CURRENT INPUTS AND E/F (11 I/P & 12 O/P) WITH 2 RS485 & ETHERNET
MOTOR PROTECTION WITH VOLTAGE & PHASE CURRENT I/Ps AND E/F (11 I/P & 12 O/P) WITH 2 RS485 & DUAL COPPER ETHERNET
MOTOR PROTECTION WITH VOLTAGE & PHASE CURRENT I/Ps AND E/F (11 I/P & 12 O/P) WITH 2 RS485 & DUAL FIBRE ETHERNET
10P24D05-1
10P24D05-2
10P24D05-3
10P24D05-4
B
B
B
B
IO option B
MOTOR PROTECTION WITH VOLTAGE & PHASE CURRENT INPUTS AND SEF (11 I/P & 12 O/P) WITH 2 RS485
MOTOR PROTECTION WITH VOLTAGE & PHASE CURRENT INPUTS AND SEF (11 I/P & 12 O/P) WITH 2 RS485 & ETHERNET
MOTOR PROTECTION WITH VOLTAGE & PHASE CURRENT I/Ps AND SEF (11 I/P & 12 O/P) WITH 2 RS485 & DUAL COPPER ETHERNET
MOTOR PROTECTION WITH VOLTAGE & PHASE CURRENT I/Ps AND SEF (11 I/P & 12 O/P) WITH 2 RS485 & DUAL FIBRE ETHERNET
10P24D06-1
10P24D06-2
10P24D06-3
10P24D06-4
B
B
B
B
IO option C
MOTOR PROTECTION WITH VOLTAGE & PHASE CURRENT INPUTS AND E/F (11 I/P & 12 O/P) WITH TCS
MOTOR PROTECTION WITH VOLTAGE & PHASE CURRENT INPUTS AND E/F (11 I/P & 12 O/P) WITH TCS & ETHERNET
MOTOR PROTECTION WITH VOLTAGE & PHASE CURRENT INPUTS AND E/F (11 I/P & 12 O/P) WITH TCS & DUAL COPPER ETHERNET
MOTOR PROTECTION WITH VOLTAGE & PHASE CURRENT INPUTS AND E/F (11 I/P & 12 O/P) WITH TCS & DUAL FIBRE ETHERNET
10P24D07-1
10P24D07-2
10P24D07-3
10P24D07-4
B
B
B
B
IO option C
MOTOR PROTECTION WITH VOLTAGE & PHASE CURRENT INPUTS AND SEF (11 I/P & 12 O/P) WITH TCS
MOTOR PROTECTION WITH VOLTAGE & PHASE CURRENT INPUTS AND SEF (11 I/P & 12 O/P) WITH TCS & ETHERNET
MOTOR PROTECTION WITH VOLTAGE & PHASE CURRENT INPUTS AND SEF (11 I/P & 12 O/P) WITH TCS & DUAL COPPER ETHERNET
MOTOR PROTECTION WITH VOLTAGE & PHASE CURRENT INPUTS AND SEF (11 I/P & 12 O/P) WITH TCS & DUAL FIBRE ETHERNET
10P24D08-1
10P24D08-2
10P24D08-3
10P24D08-4
B
B
B
B
IO option D
MOTOR PROTECTION WITH VOLTAGE & PHASE CURRENT INPUTS AND E/F (13 I/P & 12 O/P)
MOTOR PROTECTION WITH VOLTAGE & PHASE CURRENT INPUTS AND E/F (13 I/P & 12 O/P) WITH ETHERNET
MOTOR PROTECTION WITH VOLTAGE & PHASE CURRENT INPUTS AND E/F (13 I/P & 12 O/P) WITH DUAL COPPER ETHERNET
MOTOR PROTECTION WITH VOLTAGE & PHASE CURRENT INPUTS AND E/F (13 I/P & 12 O/P) WITH DUAL FIBRE ETHERNET
10P24D09-1
10P24D09-2
10P24D09-3
10P24D09-4
B
B
B
B
IO option D
MOTOR PROTECTION WITH VOLTAGE & PHASE CURRENT INPUTS AND SEF (13 I/P & 12 O/P)
MOTOR PROTECTION WITH VOLTAGE & PHASE CURRENT INPUTS AND SEF (13 I/P & 12 O/P) WITH ETHERNET
MOTOR PROTECTION WITH VOLTAGE & PHASE CURRENT INPUTS AND SEF (13 I/P & 12 O/P) WITH DUAL COPPER ETHERNET
MOTOR PROTECTION WITH VOLTAGE & PHASE CURRENT INPUTS AND SEF (13 I/P & 12 O/P) WITH DUAL FIBRE ETHERNET
10P24D10-1
10P24D10-2
10P24D10-3
10P24D10-4
B
B
B
B
IO option A MOTOR PROTECTION WITH VOLTAGE & PHASE CURRENT INPUTS AND E/F WITH SEPERATE RESIDUAL VOLTAGE INPUT 8I/P + 8O/P 10P24D12-1 B
IO option E MOTOR PROTECTION WITH VOLTAGE & PHASE CURRENT INPUTS AND E/F (3 I/P & 4 O/P) 10P24D13-1 B
IO option F MOTOR PROTECTION WITH VOLTAGE & PHASE CURRENT INPUTS AND E/F (6 I/P & 8 O/P) WITH TCS 10P24D14-1 B
IO option H
MOTOR PROTECTION WITH VOLTAGE & PHASE CURRENT INPUTS & E/F (10 I/P & 12 O/P) WITH 2 RS485
MOTOR PROTECTION WITH VOLTAGE & PHASE CURRENT INPUTS & E/F (10 I/P & 12 O/P) WITH 2 RS485 & ETHERNET
MOTOR PROTECTION WITH VOLTAGE & PHASE CURRENT INPUTS & E/F (10 I/P & 12 O/P) WITH 2 RS485 & DUAL COPPER ETHERNET
MOTOR PROTECTION WITH VOLTAGE & PHASE CURRENT INPUTS & E/F (10 I/P & 12 O/P) WITH 2 RS485 & DUAL FIBRE ETHERNET
10P24D16-1
10P24D16-2
10P24D16-3
10P24D16-4
B
B
B
B
IO option H
MOTOR PROTECTION WITH VOLTAGE & PHASE CURRENT INPUTS & SEF (10 I/P & 12 O/P) WITH 2 RS485
MOTOR PROTECTION WITH VOLTAGE & PHASE CURRENT INPUTS & SEF (10 I/P & 12 O/P) WITH 2 RS485 & ETHERNET
MOTOR PROTECTION WITH VOLTAGE & PHASE CURRENT I/Ps & SEF (10 I/P & 12 O/P) WITH 2 RS485 & DUAL COPPER ETHERNET
MOTOR PROTECTION WITH VOLTAGE & PHASE CURRENT INPUTS & SEF (10 I/P & 12 O/P) WITH 2 RS485 & DUAL FIBRE ETHERNET
10P24D17-1
10P24D17-2
10P24D17-3
10P24D17-4
B
B
B
B
IO option J
MOTOR PROTECTION WITH VOLTAGE & PHASE CURRENT INPUTS & E/F (12 I/P & 12 O/P)
MOTOR PROTECTION WITH VOLTAGE & PHASE CURRENT INPUTS & E/F (12 I/P & 12 O/P) WITH ETHERNET
MOTOR PROTECTION WITH VOLTAGE & PHASE CURRENT INPUTS & E/F (12 I/P & 12 O/P) WITH DUAL COPPER ETHERNET
MOTOR PROTECTION WITH VOLTAGE & PHASE CURRENT INPUTS & E/F (12 I/P & 12 O/P) WITH DUAL FIBRE ETHERNET
10P24D18-1
10P24D18-2
10P24D18-3
10P24D18-4
B
B
B
B
IO option J
MOTOR PROTECTION WITH VOLTAGE & PHASE CURRENT INPUTS & SEF (12 I/P & 12 O/P)
MOTOR PROTECTION WITH VOLTAGE & PHASE CURRENT INPUTS & SEF (12 I/P & 12 O/P) WITH ETHERNET
MOTOR PROTECTION WITH VOLTAGE & PHASE CURRENT INPUTS & SEF (12 I/P & 12 O/P) WITH DUAL COPPER ETHERNET
MOTOR PROTECTION WITH VOLTAGE & PHASE CURRENT INPUTS & SEF (12 I/P & 12 O/P) WITH DUAL FIBRE ETHERNET
10P24D19-1
10P24D19-2
10P24D19-3
10P24D19-4
B
B
B
B
* When selecting applicable connection diagram(s), it may be helpful to reference the appropriate model’s CORTEC.
