Appendix C – Wiring Diagrams P24xM
C2 P24xM-TM-EN-2.1
MODEL
CORTEC
OPTION*
EXTERNAL CONNECTION DIAGRAM TITLE
DRAWING-
SHEET
ISSUE
P24NM
IO option A MOTOR PROTECTION WITH PHASE CURRENT INPUTS AND E/F (8 I/P & 8 O/P) 10P24N01-1 B
IO option A MOTOR PROTECTION WITH PHASE CURRENT INPUTS AND SEF (8 I/P & 8 O/P) 10P24N02-1 B
IO option A
MOTOR PROTECTION WITH PHASE CURRENT INPUTS AND E/F (8 I/P & 8 O/P) WITH ETHERNET
MOTOR PROTECTION WITH PHASE CURRENT INPUTS AND E/F (8 I/P & 8 O/P) WITH DUAL COPPER ETHERNET
MOTOR PROTECTION WITH PHASE CURRENT INPUTS AND E/F (8 I/P & 8 O/P) WITH DUAL FIBRE ETHERNET
10P24N03-1
10P24N03-2
10P24N03-3
B
B
B
IO option A
MOTOR PROTECTION WITH PHASE CURRENT INPUTS & SEF (8 I/P 8 O/P) WITH ETHERNET & OPTIONAL SHORTING LINK
MOTOR PROTECTION WITH PHASE CURRENT INPUTS & SEF (8 I/P 8 O/P) WITH DUAL COPPER ETHERNET
MOTOR PROTECTION WITH PHASE CURRENT INPUTS & SEF (8 I/P 8 O/P) WITH DUAL FIBRE ETHERNET
10P24N04-1
10P24N04-2
10P24N04-3
B
B
B
IO option B
MOTOR PROTECTION WITH PHASE CURRENT INPUTS AND E/F (11 I/P & 12 O/P) WITH 2 RS485
MOTOR PROTECTION WITH PHASE CURRENT INPUTS AND E/F (11 I/P & 12 O/P) WITH 2 RS485 & ETHERNET
MOTOR PROTECTION WITH PHASE CURRENT INPUTS AND E/F (11 I/P & 12 O/P) WITH 2 RS485 & DUAL COPPER ETHERNET
MOTOR PROTECTION WITH PHASE CURRENT INPUTS AND E/F (11 I/P & 12 O/P) WITH 2 RS485 & DUAL FIBRE ETHERNET
10P24N05-1
10P24N05-2
10P24N05-3
10P24N05-4
B
B
B
B
IO option B
MOTOR PROTECTION WITH PHASE CURRENT INPUTS AND SEF (11 I/P & 12 O/P) WITH 2 RS485
MOTOR PROTECTION WITH PHASE CURRENT INPUTS AND SEF (11 I/P & 12 O/P) WITH 2 RS485 & ETHERNET
MOTOR PROTECTION WITH PHASE CURRENT INPUTS AND SEF (11 I/P & 12 O/P) WITH 2 RS485 & DUAL COPPER ETHERNET
MOTOR PROTECTION WITH PHASE CURRENT INPUTS AND SEF (11 I/P & 12 O/P) WITH 2 RS485 & DUAL FIBRE ETHERNET
10P24N06-1
10P24N06-2
10P24N06-3
10P24N06-4
B
B
B
B
IO option C
MOTOR PROTECTION WITH PHASE CURRENT INPUTS AND E/F (11 I/P & 12 O/P) WITH TCS
MOTOR PROTECTION WITH PHASE CURRENT INPUTS AND E/F (11 I/P & 12 O/P) WITH TCS & ETHERNET
MOTOR PROTECTION WITH PHASE CURRENT INPUTS AND E/F (11 I/P & 12 O/P) WITH TCS & DUAL COPPER ETHERNET
MOTOR PROTECTION WITH PHASE CURRENT INPUTS AND E/F (11 I/P & 12 O/P) WITH TCS & DUAL FIBRE ETHERNET
10P24N07-1
10P24N07-2
10P24N07-3
10P24N07-4
B
B
B
B
IO option C
MOTOR PROTECTION WITH PHASE CURRENT INPUTS AND SEF (11 I/P & 12 O/P) WITH TCS
MOTOR PROTECTION WITH PHASE CURRENT INPUTS AND SEF (11 I/P & 12 O/P) WITH TCS & ETHERNET
MOTOR PROTECTION WITH PHASE CURRENT INPUTS AND SEF (11 I/P & 12 O/P) WITH TCS & DUAL COPPER ETHERNET
MOTOR PROTECTION WITH PHASE CURRENT INPUTS AND SEF (11 I/P & 12 O/P) WITH TCS & DUAL FIBRE ETHERNET
10P24N08-1
10P24N08-2
10P24N08-3
10P24N08-4
B
B
B
B
IO option D
MOTOR PROTECTION WITH PHASE CURRENT INPUTS AND E/F (13 I/P & 12 O/P)
MOTOR PROTECTION WITH PHASE CURRENT INPUTS AND E/F (13 I/P & 12 O/P) & ETHERNET
MOTOR PROTECTION WITH PHASE CURRENT INPUTS AND E/F (13 I/P & 12 O/P) & DUAL COPPER ETHERNET
MOTOR PROTECTION WITH PHASE CURRENT INPUTS AND E/F (13 I/P & 12 O/P) & DUAL FIBRE ETHERNET
10P24N09-1
10P24N09-2
10P24N09-3
10P24N09-4
B
B
B
B
IO option D
MOTOR PROTECTION WITH PHASE CURRENT INPUTS AND SEF (13 I/P & 12 O/P)
MOTOR PROTECTION WITH PHASE CURRENT INPUTS AND SEF (13 I/P & 12 O/P) & ETHERNET
MOTOR PROTECTION WITH PHASE CURRENT INPUTS AND SEF (13 I/P & 12 O/P) & DUAL COPPER ETHERNET
MOTOR PROTECTION WITH PHASE CURRENT INPUTS AND SEF (13 I/P & 12 O/P) & DUAL FIBRE ETHERNET
10P24N10-1
10P24N10-2
10P24N10-3
10P24N10-4
B
B
B
B
IO option E MOTOR PROTECTION WITH PHASE CURRENT INPUTS AND EARTH FAULT (3 I/P & 4 O/P) 10P24N12-1 B
IO option F MOTOR PROTECTION WITH PHASE CURRENT INPUTS AND EARTH FAULT (6 I/P & 8 O/P) WITH TCS 10P24N13-1 B
IO option H
MOTOR PROTECTION WITH PHASE CURRENT INPUTS AND E/F (10 I/P & 12 O/P) WITH 2 RS485
MOTOR PROTECTION WITH PHASE CURRENT INPUTS AND E/F (10 I/P & 12 O/P) WITH 2 RS485 & ETHERNET
MOTOR PROTECTION WITH PHASE CURRENT INPUTS AND E/F (10 I/P & 12 O/P) WITH 2 RS485 & DUAL COPPER ETHERNET
MOTOR PROTECTION WITH PHASE CURRENT INPUTS AND E/F (10 I/P & 12 O/P) WITH 2 RS485 & DUAL FIBRE ETHERNET
10P24N14-1
10P24N14-2
10P24N14-3
10P24N14-4
B
B
B
B
IO option H
MOTOR PROTECTION WITH PHASE CURRENT INPUTS AND SEF (10 I/P & 12 O/P) WITH 2 RS485
MOTOR PROTECTION WITH PHASE CURRENT INPUTS AND SEF (10 I/P & 12 O/P) WITH 2 RS485 & ETHERNET
MOTOR PROTECTION WITH PHASE CURRENT INPUTS AND SEF (10 I/P & 12 O/P) WITH 2 RS485 & DUAL COPPER ETHERNET
MOTOR PROTECTION WITH PHASE CURRENT INPUTS AND SEF (10 I/P & 12 O/P) WITH 2 RS485 & DUAL FIBRE ETHERNET
10P24N15-1
10P24N15-2
10P24N15-3
10P24N15-4
B
B
B
B
IO option J
MOTOR PROTECTION WITH PHASE CURRENT INPUTS AND E/F (12 I/P & 12 O/P)
MOTOR PROTECTION WITH PHASE CURRENT INPUTS AND E/F (12 I/P & 12 O/P) & ETHERNET
MOTOR PROTECTION WITH PHASE CURRENT INPUTS AND E/F (12 I/P & 12 O/P) & DUAL COPPER ETHERNET
MOTOR PROTECTION WITH PHASE CURRENT INPUTS AND E/F (12 I/P & 12 O/P) & DUAL FIBRE ETHERNET
10P24N16-1
10P24N16-2
10P24N16-3
10P24N16-4
B
B
B
B
IO option J
MOTOR PROTECTION WITH PHASE CURRENT INPUTS AND SEF (12 I/P & 12 O/P)
MOTOR PROTECTION WITH PHASE CURRENT INPUTS AND SEF (12 I/P & 12 O/P) & ETHERNET
MOTOR PROTECTION WITH PHASE CURRENT INPUTS AND SEF (12 I/P & 12 O/P) & DUAL COPPER ETHERNET
MOTOR PROTECTION WITH PHASE CURRENT INPUTS AND SEF (12 I/P & 12 O/P) & DUAL FIBRE ETHERNET
10P24N17-1
10P24N17-2
10P24N17-3
10P24N17-4
B
B
B
B
* When selecting applicable connection diagram(s), it may be helpful to reference the appropriate model’s CORTEC.
