Chapter 28:
Exporting Files from Composer
Color Translations
Choose the color format for exporting.
♦ Normal exports color without modification from the plot file.
♦ Inverse filters the colors and replaces them with the negative (or inverse) color value.
For example, if an object is filled with 0% cyan, 100% magenta, 25% yellow, and 25%
black, the inverted image will contain 100% cyan, 0% magenta, 75% yellow, and 75%
black.
♦ Inverse Grays Only filters gray scale colors and replaces them with the negative color
value. All other colors export without modification.
♦ Gray Scale filters the colors and replaces them with a shade of gray (from white to
black) that represents their luminosity.
♦ Inverse Gray Scale filters the colors and replaces them with a shade of gray (from
white to black) that represents the opposite luminosity.
Line Cap Mode
♦ Device uses the line style and width that the display and printer are capable of
producing.
♦ Stroked recreates thick lines and patterned lines as polygons to more closely represent
the original artwork.
Fill Mode
♦ Device uses fill styles that the printer is capable of producing.
♦ Stroked recreates fills that most closely match the original artwork.
Background Rectangle
Adds a rectangle around the job as a border.
Exporting to a Z-soft PC Paintbrush Bitmap (PCX)
The Zsoft PC Paintbrush Bitmap (PCX)
filter creates a PCX file. In the Export
dialog box, click the Options button to
open the PCX Output Filter dialog box.
Choose from the following available
options to modify export settings:
Profiles
Choose one of the Profiles to modify the
way in which the file exports.
♦ Standard Options presets the
color format to 256 colors, the
image Resolution to 20 x 20 pixels per inch, and the image size to Screen.
