2) Check the working order of fuse No. 1.
3) Check contacts «A» and «B» of the key switch.
4) Check the main relay.
5) Check that the main relay and ground Brown-Black cable is earthed.
6) With the key switch set to «ON», check if there is voltage between the Orange cable of the main
relay and the ground connection.
7) If there is no voltage, check the continuity of the cable harness with the fuse box (fuse No. 1).
8) Check fuse No. 8 and the continuity of the cable harness with the main relay (Orange cable).
9) Check the continuity of the cable harness between fuse No. 8 and the stop buttons (Purple-White
cables).
10) Check that the stop buttons work properly.
11) Check the continuity of the cable harness between the stop buttons and the rear light (Grey-Green
cable).
12) Check that the Black cable of the rear light is earthed.
LIGHT BULBS TABLE
Specification Desc./Quantity
1 Low-beam bulb Type: HALOGEN (H7)
Power: 12V - 55W
Quantity: 1
2 High-beam light bulb Type: HALOGEN (H1)
Power: 12V - 55W
Quantity: 1
3 Front tail light bulb Type: ALL GLASS
Power: 12V - 5W
Quantity: 1
4 Front turn indicator bulb Type: WITH BULB
Power: 12V - 10W
Quantity: 1 RHS + 1 LHS
5 Rear tail light bulb Type: LED
Power: -
Quantity: 1
6 Stop light bulb Type: LED
Power: -
Quantity: 1
7 Rear turn indicator light bulb Type: WITH BULB
Power: 12V - 10W
Quantity: 1 RHS + 1 LHS
8 License plate light bulb Type: ALL GLASS
Power: 12V - 5W
Quantity: 1
9 Helmet compartment light bulb Type: FESTOON BULB
Power: 12V - 5W
Quantity: 1
10 Instrument panel bulb Type: ALL GLASS
Power: 12V - 2W
Quantity: 4
11 Turn indicator warning light bulb Type: ALL GLASS
Power: 12V - 1.4W
