Swing-arm

BRACCIO OSCILLANTE

Code Action Duration

1 003015 Traversa anteriore sostegno

motore - Sost

2 003016 Tamponi anteriori sostegno

motore - Sost

3 003017 Tampone posteriore suppor-

to motore - Sost

4 001032 Engine support pin - Replace-

ment

GP 800 i.e. Time

TIME - 31
