Specification Desc./Quantity
Protected circuits: Turn indicator control
device.
Live: Fuses No. 10-11-12.
5 Fuse No. 5 Capacity: 7.5 A
Protected circuits: Instrument panel.
6 Fuse No. 6 Capacity: 5A
Protected circuits: ECU, decoder.
7 Fuse No. 7 Capacity: 15A
Protected circuits:Low-beam light relay,
high-beam light (via relay), low-beam light
(via relay).
8 Fuse No. 8 Capacity: 10 A
Protected circuits (live): Wiring for acces-
sories, horn, stop light, high-beam light relay.
9 Fuse No. 9 Capacity: 7.5 A
Protected circuits (live): Injection load re-
lay, electrical fan relay, ECU, decoder.
10 Fuse No. 10 Capacity: 7.5 A
Protected circuits (live): Saddle opening
receiver, turn indicator control device, tail
lights, instrument panel.
11 Fuse No. 11 Capacity: 7.5 A
Protected circuits (live): Wiring for GPS,
pre-installation for antitheft device, parking
brake.
12 Fuse No. 12 Capacity: 5A
Protected circuits (live): Windshield relay,
engine for windshield (via relay).
Sealed battery
Sealed battery start-up operations
If the vehicle is provided with a sealed battery, the only maintenance required is the check of its charge
and recharging, if necessary.
These operations should be carried out before delivering the vehicle, and on a six-month basis while
the vehicle is stored in open circuit.
Besides upon pre-delivery it is therefore necessary to check the battery charge and recharge it, if re-
quired, before storing the vehicle and afterwards every six months.
INSTRUCTIONS FOR BATTERY REFRESH AFTER OPEN CIRCUIT STORAGE
1) Voltage check
Before installing the battery on the vehicle, check the open circuit voltage with a regular tester.
- If voltage exceeds 12.60 V, the battery can be installed without any renewal recharge.
- If voltage is below 12.60 V, a renewal recharge is required as explained in 2).
2) Constant voltage battery charge mode
- Constant voltage charge equal to 14.40 ÷ 14.70V
-Initial charge voltage equal to 0.3 ÷ 0.5 for Nominal capacity
- Charge time:
