LAMBDA PROBE CONNECTOR
1. Control unit (White-Green)
2. Control unit (Grey-Red)
3. Control unit (Purple)
4. Injection load relay (Black-Green)
AIR TEMPERATURE SENSOR CONNECTOR
1. Control unit (White-Grey)
2. Control unit negative (Sky Blue-Green)
WATER TEMPERATURE SENSOR CONNEC-
TOR
1. Control unit (Grey-Green)
2. Instrument panel (Green-Yellow)
3. Control unit negative (Sky Blue-Green)
4. Instrument panel (Brown-Black)
VEHICLE SPEED SENSOR CONNECTOR
1. Control unit negative (Sky Blue-Green)
2. Vehicle speed signal (Brown-Red)
3. Control unit positive (Red-Blue)
Electrical system GP 800 i.e.
ELE SYS - 60
