Centre-stand

STAND

Code Action Duration

1 004004 Stand - Replacement

2 004179 Stand buffer - Replacement

3 001053 Stand bolt - Replacement

4 004102 Side stand - Replacement

Time GP 800 i.e.

TIME - 22
