Gilera GP 800 i.e.

To Next Page

To Previous Page

WIRE UNIT

Code Action Duration

1 005001 Electrical system - Replace-

ment

2 005114 Electrical system - Service

3 820021 Engine cable harness - Re-

plac.

Time GP 800 i.e.

TIME - 42
