Gilera GP 800 i.e. - Clutch Ring Nut

- Screw the locking ring nut and tighten to the pre-
scribed torque.
Locking torques (N*m)
Clutch ring nut 65 - 75
- With a specific tool, separate the two half-pulleys
and fit the belt according to its direction of rotation.
CAUTION
PLACE THE TWO HALF-RINGS ADEQUATELY
SO THAT THEY PERFECTLY ADHERE TO THE
HALF-PULLEY.
- Screw the tool so as to separate the two half-
pulleys.
Engine GP 800 i.e.
ENG - 14
