Gilera GP 800 i.e. - Inspecting the Flywheel Components; Starter Gear Rim

- Undo the five fixing screws and remove the oil
pump compartment closing bulkhead.
- Remove the intermediate gear.
Inspecting the flywheel components
- Check the integrity of the magnets.
- Check that the magnet support cage is free from
deformation or cracks.
Starter gear rim
- Check that there is no wear or abnormal impres-
sions on the "rollers" of the freewheel and on the
surface of the starter ring gear hub.
- Check the hub outside diameter.
Characteristic
Hub outside diameter:
Diameter 45.665 + 0.008 +0.005 mm
GP 800 i.e. Engine
ENG - 41
