Parking brake
PARKING BRAKE CALLIPER REMOVAL
- Undo the two screws and remove the protection.
- Loosen the nut indicated and remove the trans-
mission.
- Undo the two screws and remove the calliper.
- To refit, carry out the previous operations but in reverse order. After adjustment, tighten the nut indi-
cated to the prescribed torque.
Locking torques (N*m)
Screw fixing parking brake calliper to supporting plate 24 ÷ 27 Parking brake adjusting nut 10
