Gilera GP 800 i.e. - Brake Pipes; Brake Pump Coupling; Front Brake Pipe Fitting

- Remove the two screws fixing the pump to the
handlebar.
Refitting
- To refit, carry out the removal operations but in reverse order.
CAUTION
ONCE REFITTING IS FINISHED, BLEED THE SYSTEM.
Locking torques (N*m)
Screws fixing brake pump to handlebar 7 ÷ 10 Brake pipes / brake pump coupling 16 ÷ 20
Brake pipes
FRONT BRAKE PIPE FITTING
- Fix the three-way union to the fork head.
Locking torques (N*m)
Screw fixing three-way union to fork head 10 ÷
12
- Fit the front brake pipes to the right and the left.
Locking torques (N*m)
Brake pipes / three-way union coupling 18 ÷
23 Brake pipes / front brake calliper coupling
16 ÷ 20
Braking system GP 800 i.e.
BRAK SYS - 14
